Kipor IG2000 - Crankcase Cover Assembly

75
12.5 Assembly of crankcase cover
1. Clean any remaining sealant on the cylinder block and crankcase cover with cloth.
2. Apply gasket sealant on the cylinder block sealing face, as shown.
3. Reassemble the crankcase cover in the opposite direction of disassembly.
Caution
Install the crankcase cover on the cylinder block within three minutes after applying sealant.
Revolve the crankshaft if necessary.
