Kipor IG2000 Shop Manual

76
4. Tighten the crankcase cover bolt slowly to the prescribed torque.
5. Wait 20 minutes after installation before filling with oil and starting the engine
直径1.5-2mm密封胶
机体
12.6 Inspection
● Inspection of oil alarm
(1) Stand the oil alarm, check the oil alarm output wire and copper earth wire, there should be no
continuity.
(2) Bottom up the oil alarm; check again, there should be continuity.
(3) Bottom up the oil alarm completely in the oil, check the float, there should be no continuity.
Sealant: 1-1.5mm diameter
Cylinder block
© 2011 Kipor Power Systems, Inc.

Kipor IG2000 Specifications

General

Rated Power	1.6 kW
Voltage	230 V
Frequency	50 Hz
Fuel Type	Gasoline
Starting System	Recoil
Weight	22 kg
Engine Type	4-stroke, OHV
Noise Level	54-59 dB(A)
Continuous Operation Time	4 h (at rated load)
