Kipor IG2000 Shop Manual

43
NOTE: With the exception of changing the main jet, no adjustments, modifications, or other
maintenance is permitted on EPA and CARB certified engines. This includes any Kipor generator
ever sold in North America. This drawing is for information only. Kipor will not supply any
carburetor parts other than stepping motors and main jets
6.3 Inspection
● Float height
Place the carburetor on a level surface as shown; measure the float height between the float and
carburetor block.
Height 12mm
Replace the carburetor if the float height is not correct.
浮子
12
Float
© 2011 Kipor Power Systems, Inc.

Kipor IG2000 Specifications

General

Rated Power	1.6 kW
Voltage	230 V
Frequency	50 Hz
Fuel Type	Gasoline
Starting System	Recoil
Weight	22 kg
Engine Type	4-stroke, OHV
Noise Level	54-59 dB(A)
Continuous Operation Time	4 h (at rated load)
