46
●IG2000\IG2000S
交流插座
点火器
直流插座
smart开关
接地端
7.2 Inspection
a. Control panel
● AC receptacle
Check the electrode contact disk inside receptacle, if it is burnt or the discolored, replace it.
● DC receptacle
Connect both terminals of the receptacle with a jumper wire to short. There must be continuity
between the lead wire terminals with the circuit protector ON. Replace the DC receptacle if there
is no continuity.
● Smart switch
There should be continuity with the switch ON, and no continuity with the switch OFF.
Igniter
AC receptacle
Ground terminal
Smart throttle switch
DC receptacle
