Kirisun DP580 Service Manual

DP580 Service Manual
SN Material Code Material Name Specification QTY
4 7MHP-4207-05A-W0
Side key cap (up) for radio
DP586 (cover die 1)
PC1414, black, etched
1
5 7MHP-4207-01A-W0
Plastic PTT key for radio
DP586
PC1414, co-molding dual-color,
pantone 172c+, black
1
6 7MHR-4207-03B-W0
Silicon PTT key for radio
DP586
Silicon rubber, black, hardness
60±5°
1
7 7MHR-4207-05A-WC Light pipe for radio DP586
Silicon rubber, hardness 60±5°,
transparent
1
8 7MHR-4207-04A-W3 Alarm key for radio DP586
Silicon rubber, pantone 172C,
hardness 60±5°
1
9 7MHP-4182-02A-W0
Encoding knob for radio
DP990 (cover die 2)
PC1414, black, etched, oiled
gray
1
10 7MHP-4182-01A-W0
Volume knob for radio
DP990 (cover die 2)
PC1414, black, etched, oiled
gray
1
11 7MHS-4072-08A-W STP knob circlip
Stainless steel, T=0.3, original
color
2
12 7NRC-4078-01A-N
Antenna connector nut for
radio TP660
Brass, black nickel plated 1
13 7MHC-4072-01A-W STP knob nut
Brass, inner diameter 6mm,
outer diameter 9mm, 2.4mm
thick
2
14 7MHJ-4207-02B-W
Dual-sided adhesive tape
for earphone FPCB (for
radio DP586)
3M9448, square, 20.3*7.8mm
1
15 4SS7-3605-016-100D Speaker Φ36mm, H5mm, 16Ω, 1W 1
16 7GCM-411294-J
Sponge mat for LCD
screen of radio FP560
PRON, with pad, 41.1*29.4mm,
single-sided adhesive
1
17 6MD7-F04932-C LCD module for radio W60
Black-and-white screen, 128*64
pixels, ultra-wide temperature
range
1
18 7MHS-4245-02A-W LCD hardware holder
SUS304, 48hr salt spray test
passed
1
19
7STF-019040B-SZPT
-N
R M1.9*4 cross recessed
flat-head self-tapping
Phillips screw
Hardened iron 1018,
Φ1.9mm*4mm
2
21
