Kirisun DP580 Service Manual

DP580 Service Manual
SN Material Code Material Name Specification QTY
20
7SMF-020040M-SZY
B-N
R M2*4 cross recessed
mushroom-head machine
screw
Hardened iron, Φ2mm*4mm,
nickel plated
13
21 7MHR-4072-05A-W0 O-shaped ring
Silicon rubber, outer diameter 8
mm, wire diameter 1.5 mm
2
22 Main board 1
23
7SMF-020037M-SZC
T-N
M2.0*3.7 cross recessed
countersunk-head
machine screw
Hardened iron 1018,
Φ2.0mm*3.7mm, nickel plated
2
24 7MHS-4207-03A-W
PTT metal dome array for
radio DP586
SUS301, Φ5mm, four-point
metal dome
1
25 6PD7-4207-HPB PTT board for radio DP586
DP586_PTT_1600707,
thickness 0.8MM, FR-4
1
26 7MHR-4207-06A-W0
O-shaped ring of
antenna
pedestal for radio DP586
Silicon rubber, outer diameter
11 mm, wire diameter 1.5 mm
1
27
3CR7-SMA-50JF-4
RF coaxial cable
SMA-J, install using flange
1
28 7MHP-4207-03A-W0
Top cover for radio DP586
(cover die 1)
PC1414, black 1
29
6SS3-DC7258-A
KB-75A battery
7.4V, 2000mAh, Li-ion battery
1
30 6SS3-BJ4038-B
KBJ-17 belt clip (S series,
coarse textured)
Belt clip for radio S760/DP405 1
31
7SMS-025075M-SZY
B-N1
Torx mushroom-head
machine screw
Stainless steel, M2.5*7.5 2
32 7MHR-4207-01A-W3
Waterproof ring for radio
DP586
Silicon rubber, pantone 172C,
hardness 40±5°
1
33 7MHR-4072-03E-W3
STP waterproof pad for
discharge
Hardness 30°, silicon rubber,
orange, PT172C
1
34
7SMF-025080M-SZY
B-Z
M2.5*8 cross
round-and-mushroom
headed machine screw
Stainless steel, Φ2.5mm*8mm,
black zinc plated
2
35 7MHR-4072-06A-W0 O-shaped ring
Silicon rubber, outer diameter 4
mm, wire diameter 1.0 mm
2
36 7MHL-4207-01B-W
Aluminum housing for
radio DP586
ADC12, surface grinding, sand
blasting, paint spraying
1
37 7MHR-7042-06C-W0
R heat-conducting silicon
pad
Silicon rubber, black, 3*6*9mm,
hardness 20°
1
38 3WF7-05030-500C4 FPC cable
Spacing 0.5mm, 30P, 50mm
long
1
