Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
6
2CC1-10-X7R500-10
3K
R multi-layer chip
capacitor
1005,10nF±10%, 50V, X7R 22
C21,C183,C188,C195,C197,C218,C220,C224,C225,C232,C2
33,C238,C253,C293,C55,C326,C327,C328,C329,C331,C356
,C357
7
2CC1-10-X7R160-10
4K
R multi-layer chip
capacitor
1005, 100nF±10%, 16V, X7R 86
C24,C48,C73,C91,C92,C95,C96,C103,C104,C110,C111,C12
6,C128,C139,C141,C143,C152,C155,C156,C158,C159,C161
,C234,C244,C249,C260,C264,C281,C283,C294,C296,C298,
C475,C333,C334,C340,C346,C349,C359,C437,C549,C550,C
67,C68,C423,C424,C425,C426,C427,C428,C440,C441,C455
,C456,C544,C545,C433,C435,C442,C449,C450,C453,C454,
C457,C458,C461,C386,C387,C436,C451,C478,C479,C485,C
491,C492,C498,C499,C505,C506,C507,C42,C459,C460,C46
6,C518,C519
8
2CC1-20-X5R160-10
6KD
Multi-layer chip capacitor
2012, 10uF±10%, 16V, TAIYO,
EMK212ABJ106KD-T,
0.85±0.1mm high
46
C32,C35,C39,C307,C393,C398,C403,C404,C448,C527,C530
,C533,C535,C5,C312,C315,C47,C85,C88,C149,C236,C237,
C163,C166,C338,C348,C44,C46,C50,C370,C371,C373,C374
,C376,C377,C381,C382,C391,C399,C59,C60,C418,C421,C4
44,C445,C500
9
1DR1-NSR1020MW2
T1G
SMD Schottky barrier
diode
NSR1020MW2T1G, lead free 1 D1
10 1DZ1-PESD12VS1UB
SMD voltage regulator
diode
PESD12VS1UB, lead free 1 D2
11
1DR1-1SR154-400
R SMD rectifier diode
1SR154-400, 4532
1
D3
12 3FW1-42932-302320 R SMD fuse
(SC)429003/433003/466003,
3216, 3A/32V
1 F1
13 5FE1-BLM11A601S R SMD EMI filter
1608,
BLM11A601S/BLM18AG601S(0
138-05)
7 FB1,FB4,FB11,L68,L69,L70,L71
29
