DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
14 5FE1-CB100505-102 R SMD EMI filter 1005,1KΩ [Made in China] 27
FB38,FB39,FB40,FB17,FB20,FB41,FB47,FB48,FB5,FB6,FB7
,FB8,FB9,FB10,R38,FB14,FB15,FB18,FB46,R222,R246,R25
4,R255,R256,R271,R272,R273
15 1IS1-MP2359
SMD switch power supply
IC
MP2359, 6PIN, 1.2A 24V,
1.4MHz, TSOT-23-6
1 IC1
16 1IS1-XC6209B552MR SMD voltage regulator IC 5.5V, SOT-23-5 encapsulation 1 IC3
17 1IS1-XC6209F502PR SMD voltage regulator IC
XC6209F502PR, SOT-89-5,
5.0V
1 IC24
18 7MHP-4002-01C-W TD7700 Battery connector
BC-2P-4.1PH-6.8H; shrapnel:
0.3mm higher, 7.5mm high
1 J1
19 2LW1-35UF-472KB SMD wire wound inductor
3.5*3.0*2.1, 4.7UH±20%,
PIO32-4R7MT, lead free
3 L1,L62,L63
20 1TF1-ST2301
R SMD field effect
transistor
ST2301A, SOT-23 5 Q17,Q23,Q102,Q29,Q26
21 1TT1-DTC144EE R SMD triode
Digital triode, DTC144EE (26),
SOT323
9 Q22,Q24,Q25,Q2,Q18,Q19,Q20,Q21,Q27
22 2RS1-10-103J R chip resistor 1005, 10K±5% 43
R1,R28,R32,R39,R50,R51,R214,R109,R229,R175,R176,R17
7,R178,R10,R11,R291,R292,R293,R294,R192,R195,R224,R
269,R298,R197,R200,R203,R204,R205,R206,R210,R230,R2
42,R243,R244,R245,R265,R266,R267,R268,R277,R278,R27
9
23 2RE1-10-6802 Precise SMD resistor 1005, 68K±1% 1 R3
24
2RE1-10-1602
Precise SMD resistor
1005, 16.2K±1%
1
R4
25 2RS1-10-102J R chip resistor 1005, 1K±5% 13
R5,R6,R8,R147,R258,R78,R97,R144,R127,R128,R182,R199
,R201
26 2RS1-10-334J R chip resistor 1005, 330K±5% 1 R145
30
