DP580 Service Manual
27 2RS1-10-104J R chip resistor 1005, 100K±5% 15
R146,R155,R262,R264,R57,R58,R59,R94,R106,R107,R115,
R116,R307,R29,R228
28 2RS1-10-471J R chip resistor 1005, 470Ω±5% 8 R154,R261,R263,R231,R306,R259,R260,R301
29
2CC1-10-C0G500-2R
R multi-layer chip
1005, 2.5P±0.1P, 50V, C0G 5 C69,C70,C71,C477,C173
30
0B
Multi-layer chip capacitor 1005, 2P±0.1P, 50V, C0G 1 C72
31
2CC1-10-C0G500-5R
R multi-layer chip
1005, 5P±0.25P, 50V, C0G 1 C75
32
8C
Multi-layer chip capacitor 1005, 6.8P±10%, 50V, C0G 2 C79,C80
33
2CC1-10-C0G500-47
R multi-layer chip
1005, 47P±5%, 50V, C0G 1 C476
34 2RS1-10-000O R chip resistor 1005, 0Ω 56
C480,R170,R171,R173,R311,R313,R34,R140,R142,C174,R7
2,R80,R137,R220,C358,R169,R326,FB21,FB22,FB23,R157,
R179,R183,R184,R185,FB24,FB25,FB26,FB27,R186,R187,R
281,R282,R283,R284,FB28,FB29,FB30,FB31,FB32,FB33,FB
34,FB35,FB36,FB37,R22,R152,R232,R233,R234,R235,R257
,R274,R275,R276,R300
35
2CC1-10-X5R100-10
5K
Multi-layer chip capacitor 1005, 1uF±10%, 10V, X5R 26
C482,C483,C486,C488,C489,C493,C495,C496,C350,C351,C
363,C364,C365,C366,C367,C306,C413,C414,C416,C542,C4
84,C490,C497,C504,C401,C463
36 1IS1-XC6209F332M SMD voltage regulator IC
XC6209F332MR
3 IC15,IC8,IC6
37 2LL1-16-3N9SA Multi-layer chip inductor
1608, 3.9nH±0.3nH
(SDCL1608C3N9STDF),
SunLord
2 L2,L3
31
To Next Page
