Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
38 2LL1-16-10NJA Multi-layer chip inductor
1608, 10nH±5%
(SDCL1608C10NJTDF),
SunLord
1 L4
39
2LG1-VLS3012ET-10
0M
SMD power inductor
VLS3012ET-100M, 10uH+20%,
3*3*1.2MM
1 L5
40 2LL1-16-8N2DA Multi-layer chip inductor
1608, 8.2nH±0.5nH
(SDCL1608C8N2JTDF),
SunLord
1 L6
41 2RS1-10-473J R chip resistor 1005, 47K±5% 9 R12,R18,R52,R119,R123,R226,R227,R153,R302
42 1IS1-AT2659 Low-noise amplifier
AT2659, 1550~1615 MHz, 6-pin
DFN, ICOFCHINA
1 U2
43
1IS1-UBX-M8030
GPS IC
GPS chip, UBX-M8030, UBLOX
1
U3
44
5OT1-26R0-DSB221
SDN
SMD temperature
compensated crystal
oscillator
26MHz±0.5ppm, -30℃~+85℃,
1.8V, 2.5*2.0, lead free
1 X101
45
5XT1-TFX02S-32R76
8
SMD ceramic resonator
32.768KHZ, TFX-02S, 7PF,
3215, 20PPM, lead free
1 Y1
46
2CC1-10-C0G500-10
1J
R multi-layer chip
capacitor
1005, 100P±5%, 50V, C0G 23
C86,C89,C116,C131,C380,C164,C167,C335,C336,C341,C34
2,C343,C344,C345,C347,C353,C354,C394,C395,C397,C400
,C429,C430
47
2CC1-10-X7R500-33
2K
R multi-layer chip
capacitor
1005, 3300P±10%, 50V, X7R 3 C109,C160,C554
48
2CC1-32-X7R251-47
3K
Multi-layer chip capacitor
3216, 47nF±10%, 250V, X7R,
GRM31CR7272E473K
1 C112
49
2CT1-TS32-160-3R3
M
R SMD Tantalum capacitor
3216, 3.3μF±20%, 16V, TS
series (Encapsulation A)
1 C113
32
