DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
63
2CC1-10-X7R500-47
1K
R multi-layer chip
capacitor
1005, 470P±10%, 50V, X7R 7 C150,C151,C181,C229,C230,C231,C385
64
2CT1-TP20-100-4R7
M
R SMD Tantalum capacitor
2012, 4.7μF±20%, 10V, TP
series (Encapsulation P)
1 C402
65
1DV1-1SV325
R SMD varactor
1SV325 (V8)
8
D4,D5,D6,D7,D8,D9,D10,D11
66
1DS1-DA2S10100L
R SMD switch diode
DA2S10100L
1
D12
67 1DV1-1SV305 R SMD varactor 1SV305 6 D13,D18,D19,D21,D22,D29
68 1IS1-LMX2571NJKT Phase-locked loop IC
Texas Instruments, model
LMX2571NJKT, 36-pin WQFN
encapsulation
1 IC7
69 1TC1-UMC4 R SMD Darlington tube
UMC4, NPN/PNP Darlington
tube
2 IC10,IC14
70 1IS1-OPA348 Operational amplifier IC
Model OPA348, SC70-5
encapsulation
2 IC11,IC12
71 2LW1-25UC-471K
R SMD wire wound
inductor
2520, 0.47μH±10%, ceramic
core (FLM2520-R47K)
2 L8,L73
72 2LW1-16UC-102J SMD wire wound inductor
1608, 1uH±5%
( MLG1608S1R0JT)
2 L9,L15
73 2LW1-20UC-68NG SMD wire wound inductor
2012, 68nH±2%, SAGAMI,
C2012C-68NG
1 L10
74 2LW1-20UC-560GA SMD wire wound inductor
56NG, 2012.56N, ±2%
(C2012C-560G)
1 L11
75 2LW1-16UC-R33G SMD wire wound inductor
1608, 330nH±2%
(C1608BR33G), lead free
9 L12,L13,L14,L18,L19,L20,L50,L51,L56
76 2LW1-20UC-470GA
R SMD wire wound
inductor
2012, 47nH±2%, ceramic core
(C2012C-47NG)
2 L16,L17
34
