Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
77 2LL1-16-18NG Multi-layer chip inductor
1608, 18nH±2%
(ELJRE18NGFA)
1 L21
78 2LW1-16UC-181J SMD wire wound inductor
1608, 180nH±5%, ceramic core
(C1608CB-R18J)
3 L27,L31,L47
79 1TT1-BFU550A RF triode
BFU550A, NXP, SOT23
encapsulation
4 Q3,Q104,Q9,Q12
80 1TT1-2SC4617-R R SMD triode 2SC4617-R (BR), EMT3 1 Q4
81 1TT1-SSM3J15FS Switch triode SSM3J15FS, PMOS 1 Q5
82 1TT1-2SC5086 R SMD triode
Tube power amplifier,
2SC5086-O
3 Q7,Q13,Q14
83
2RS1-10-101J
R chip resistor
1005, 100Ω±5%
8
R24,R25,R26,R27,R41,R45,R49,R66
84 2RS1-10-6R8J Chip resistor 1005, 6.8Ω±5% 4 R30,R31,R33,R325
85 2RS1-10-332J R chip resistor 1005, 3.3K±5% 1 R35
86 2RS1-10-181J R chip resistor 1005, 180Ω±5% 2 R36,R44
87 2RS1-10-470J R chip resistor 1005, 47Ω±5% 4 R37,R99,R111,R135
88 2RS1-10-121J R chip resistor 1005, 120Ω±5% 1 R40
89
2RS1-10-822J
R chip resistor
1005, 8.2K±5%
3
R42,R55,R202
90
2RS1-10-392J
R chip resistor
1005, 3.9K±5%
5
R43,R46,R48,R56,R108
91
2RS1-10-562J
R chip resistor
1005, 5.6K±5%
1
R47
92
2RS1-10-123J
R chip resistor
1005, 12K±5%
1
R53
93
2RS1-10-273J
R chip resistor
1005, 27K±5%
1
R54
94 2RS1-10-124J R chip resistor 1005, 120K±5% 1 R64
95 2RS1-10-680J R chip resistor 1005, 68Ω±5% 1 R215
96
5OT1-12R8-ADL4-32
25
SMD temperature
compensated crystal
NDK, 12.8MHz±2.5ppm,
Vc=0~3V, frequency pull range
1 U9
