Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
oscillator ±37ppm, -40℃~85℃, 3225
encapsulation
97
2CC1-16-C0G500-47
0J
R multi-layer chip
capacitor
1608, 47P±5%, 50V, C0G 1 C14
98
2CC1-16-C0G500-33
0J
Multi-layer chip capacitor 1608, 33P±5%, 50V, C0G 1 C57
99
2CC1-16-C0G500-68
0J
R multi-layer chip
capacitor
1608, 68P±5%, 50V, C0G 1 C76
100
2CC1-16-C0G500-15
0J
R multi-layer chip
capacitor
1608, 15P±5%, 50V, C0G 2 C77,C208
101
2CC1-16-C0G500-27
0J
R multi-layer chip
capacitor
1608, 27P±5%, 50V, C0G 1 C78
102
2CC1-10-C0G500-36
0J
R multi-layer chip
capacitor
1005, 36P±5%, 50V, C0G 1 C184
103
2CC1-10-X7R160-47
3K
R multi-layer chip
capacitor
1005, 47nF±10%, 16V, X7R 1 C191
104
2CC1-16-X7R500-10
2K
R multi-layer chip
capacitor
1608, 1000P±10%, 50V, X7R 1 C207
105
2CC1-16-C0G500-9R
0C
R multi-layer chip
capacitor
1608, 9P±0.25P, 50V, C0G 1 C209
106
2CC1-16-C0G500-5R
0C
R multi-layer chip
capacitor
1608, 5P±0.25P, 50V, C0G 1 C210
107
2CC1-16-C0G500-12
0J
R multi-layer chip
capacitor
1608, 12P±5%, 50V, C0G 1 C211
108
2CC1-16-C0G500-18
0J
R multi-layer chip
capacitor
1608, 18P±5%, 50V, C0G 1 C212
36
