Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
109
2CC1-16-C0G500-20
0J
R multi-layer chip
capacitor
1608, 20P±5%, 50V, C0G 1 C213
110
2CC1-16-C0G500-11
0J
R multi-layer chip
capacitor
1608,11P±5%,50V,C0G 1 C214
111
2CC1-16-C0G500-22
0J
R multi-layer chip
capacitor
1608, 22P±5%, 50V, C0G 1 C215
112
2CC1-10-C0G500-27
1J
Multi-layer chip capacitor 1005, 270P±5%, 50V, C0G 2 C222,C227
113
2CC1-10-X7R160-82
2K
R multi-layer chip
capacitor
1005, 8200P±10%,1 6V, X7R 1 C223
114
2CC1-10-X7R500-15
3K
R multi-layer chip
capacitor
1005, 15nF±10%, 50V, X7R 1 C228
115
1DS1-RN142S
SMD switch diode
RN142S, 1608 (ROHM)
2
D14,D15
116
1DS1-1SS390
SMD switch diode
1SS390, 1608
2
D16,D17
117 5FE1-BLM21P300S R SMD EMI filter
2012,
BLM21P300S/BLM21PG300S
(0149-05)
1 FB12
118 1IL1-NJM2904V R SMD linear IC
Operational amplifiers
NJM2904V and TSSOP-8
1 IC13
119 2RS1-16-000O R chip resistor 1608, 0Ω 2 L28,L55
120 2LW1-16UC-560G SMD wire wound inductor
1608, 56nH±2%, ceramic core
(C1608CB-56NG)
1 L30
121 2LW1-16UC-270G SMD wire wound inductor
1608, 27nH±2%, ceramic core
(C1608CB-27NG)
2 L32,L35
122 2LW1-25UC-102JA
R SMD wire wound
inductor
2520, 1μH±5%, ceramic core
(FHW1008UC1R0J)
1 L33
