Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
123
2RS1-16-560J
R chip resistor
1608, 56Ω±5%
1
L34
124
2LH1-R401R5-R08-0
5
R SMD air core inductor
(SC) wire diameter φ 0.40, inner
diameter φ 1.5, 8-wind, forward
winding, long pin
1 L36
125 2LH1-R301R0-L07-05 R SMD air core inductor
Wire diameter φ 0.30, inner
diameter φ 1.0, 7-wind, reverse
winding, long pin
1 L38
126
2LH1-R401R5-L07-05
R SMD air core coil
0.4*1.5*7TL, reverse, long pin
1
L39
127 2LH1-R401R5-L08-05 R SMD air core inductor
Wire diameter φ 0.40, inner
diameter φ 1.5, 8-wind, reverse
winding, long pin
1 L40
128 2LH1-R301R0-L08-05 R SMD air core inductor
Wire diameter φ 0.30, inner
diameter φ 1.0, 8-wind, reverse
winding, long pin
1 L41
129 2LW1-16UC-470G SMD wire wound inductor
1608, 47nH±2%, ceramic core
(C1608CB-47NG)
1 L42
130 2LL1-16-R22JA Multi-layer chip inductor
1608, 0.22uH±5%, [Made in
China] (CH160808-R22J)
1 L43
131 2LW1-20UC-8R2J SMD wire wound inductor
2012, 8.2nH±5%, ceramic core
(C2012C-8N2J)
1 L66
132 2LH1-R401R2-L03-05 SMD air core inductor
Wire diameter φ 0.40, inner
diameter φ 1.2, 3-wind, reverse
winding, long pin
1 L79
133 2LH1-R301R0-L04-05
SMD air core inductor
Wire diameter φ 0.30, inner
diameter φ 1.0, 4-wind, reverse
winding, long pin
1 L80
38
