Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
134 2LH1-R301R2-L05-05 SMD air core inductor
Wire diameter φ 0.30, inner
diameter φ 1.2, 5-wind, reverse
winding, long pin
1 L81
135 2LW1-20UC-221J
R SMD wire wound
inductor
2012, 220nH±5%, ceramic core
(LQN21AR22J/LQW2BHNR22J
03L)
1 L316
136
1TF1-RD01MUS2-50
1
ER SMD field effect
transistor
Mitsubishi, RD01MUS2-T513
tray package, lead free
1 Q10
137
1TF1-RD07MUS2B-5
01
ER SMD field effect
transistor
Mitsubishi, RD07MUS2B-T512
tray package, lead free
1 Q11
138
2RS1-10-390J
Chip resistor
1005, 39Ω±5%
1
R67
139
2RS1-10-151J
R chip resistor
1005, 150Ω±5%
2
R68,R69
140
2RS1-10-682J
R chip resistor
1005, 6.8K±5%
2
R75,R77
141 2RS1-10-330J R chip resistor 1005, 33Ω±5% 20
R76,R164,R165,R166,R167,R168,R148,R60,R149,
R150,R151,R188,R189,R191,R207,R208,R209,
R236,R237,R238
142
2RS1-10-100J
R chip resistor
1005, 10Ω±5%
2
R79,R249
143
2RS1-16-103J
R chip resistor
1608, 10K±5%
1
R81
144 2RS1-32-R39J R chip resistor 3216, 0.39Ω±5% 3 R82,R83,R84
145 2RE1-10-1003 Precise SMD resistor 1005, 100K±1% 4 R85,R86,R88,R90
146 2RE1-10-1004 R precise SMD resistor 1M 1005, 1M±1% 2 R87,R89
147 2RS1-10-271J R chip resistor 1005, 270Ω±5% 1 R91
148 2RS1-10-222J R chip resistor 1005, 2.2K±5% 9 R92,R110,R121,R125,R156,R190,R239,R240,R241
149 2RS1-10-363J R chip resistor 1005, 36K±5% 3 R93,R120,R124
150 2RS1-10-203J R chip resistor 1005, 20K±5% 1 R95
39
