Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
151
2RS1-10-393J
R chip resistor
1005, 39K±5%
2
R100,R132
152
2RS1-10-823J
R chip resistor
1005, 82K±5%
3
R101,R129,R304
153
2RS1-10-510J
Chip resistor
1005, 51Ω±5%
2
R102,R118
154 2RS1-10-333J R chip resistor 1005, 33K±5% 3 R103,R250,R251
155 2RS1-16-101J R chip resistor 1608, 100Ω±5% 2 R104,L53
156
2CC1-10-C0G500-22
1J
R multi-layer chip
capacitor
1005, 220P±5%, 50V, C0G 15
C240,C243,C247,C248,C256,C259,C263,C270,C274,C275,C
278,C291,C303,C473,C474
157
2CC1-10-C0G500-43
0J
R multi-layer chip
capacitor
1005, 43P±5%, 50V, C0G 1 C242
158
2CC1-10-C0G500-39
0J
R multi-layer chip
capacitor
1005, 39P±5%, 50V, C0G 3 C258,C301,C452
159
2CC1-10-C0G500-13
0J
R multi-layer chip
capacitor
1005, 13P±5%, 50V, C0G 1 C268
160
2CC1-10-X7R500-33
1K
R multi-layer chip
capacitor
1005, 330P±10%, 50V, X7R 3 C271,C65,C66
161
2CC1-10-C0G500-16
0J
Multi-layer chip capacitor 1005, 16P±5%, 50V, C0G 2 C284,C287
162
2CC1-10-C0G500-7R
0C
Multi-layer chip capacitor 1005, 7P±0.25P, 50V, C0G 2 C285,C292
163
2CC1-10-C0G500-15
0J
R multi-layer chip
capacitor
1005, 15P±5%, 50V, C0G 2 C286,C288
164
2CC1-10-C0G500-27
0J
R multi-layer chip
capacitor
1005, 27P±5%, 50V, C0G 2 C290,C302
165
2CC1-10-C0G500-6R
0C
R multi-layer chip
capacitor
1005, 6P±0.25P, 50V, C0G 1 C300
40
