DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
166 1DS1-RB706F-40 R SMD switch diode
Schottky barrier diode
RB706F-40, SOT-323
encapsulation
1 D20
167 2LW1-16UC-180G SMD wire wound inductor
1608, 18nH±2%, ceramic core
(C1608CB-18NG)
7 L22,L58,L60,L74,L75,L76,L77
168 2LW1-20UC-220J
R SMD wire wound
inductor
2012, 22nH±5%, ceramic core
(C2012C-22NJ)
5 L44,L45,L48,L49,L67
169 2LL1-16-15NJA Multi-layer chip inductor
1608, 15nH±5%
(SDCL1608C15NJTDF),
SunLord
1 L46
170 2LI1-1608-R39G Radial choke inductor
0603, 390nH±2%, Murata,
LQW18ANR39G00
1 L52
171 2LL1-16-1R0KB Multi-layer chip inductor
1608, 1μH±10%
(SDFL1608Q1R0KTFB02),
SunLord
1 L54
172 2LW1-16UC-271G SMD wire wound inductor
1608, 270nH±2%, ceramic core
(C1608CB-R27G-RF)
1 L57
173 2LW1-16UC-680G SMD wire wound inductor
1608, 68nH±2%, ceramic core
(C1608CB-68NG)
1 L59
174 2LL1-16-18NJA Multi-layer chip inductor
1608, 18nH±5%
(SDCL1608C18NJTDF),
SunLord
1 L72
175
1TT1-2SC5108-Y
R SMD triode
2SC5108-Y(MC), NPN
3
Q15,Q16,Q28
176
2RS1-10-180J
R chip resistor
1005, 18Ω±5%
1
R112
177 2RS1-10-301J R chip resistor 1005, 300Ω±5% 2 R113,R114
178 2RS1-10-105J R chip resistor 1005, 1M±5% 2 R117,R162
41
