Page #45 background imageLoading...
Page #45 background image
DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
179
2RS1-10-182J
R chip resistor
1005, 1.8K±5%
2
R122,R126
180
2RS1-10-684J
R chip resistor
1005, 680K±5%
1
R130
181
2RS1-10-184J
R chip resistor
1005, 180K±5%
1
R133
182 2RS1-10-150J R chip resistor 1005, 15Ω±5% 1 R136
183 1IS1-ADEX10L SMD mixer
Mini-Circuits, model
ADEX-10L+, lead free
1 Z1
184
5XC1-50R0-49910GQ
9
Crystal oscillator
1D49910GQ9, 49.95MHz, 7*5,
KDS
1 Z2
185 1IM1-AK2365A FM demodulation chip
FM IF detector with narrow band
filter, model AK2365A, 32-pin
1 IC17
186 2LL1-16-R47KB Multi-layer chip inductor
1608, 0.47μH±10%
(SDFL1608LR47KTFB04),
SunLord
1 L61
187 2RE1-10-4702 Precise SMD resistor 1005, 47K±1% 1 R158
188
2RS1-10-154J
R chip resistor
1005, 150K±5%
2
R159,R13
189
2RS1-10-224J
R chip resistor
1005, 220K±5%
1
R161
190
2RS1-10-683J
R chip resistor
1005, 68K±5%
3
R163,R7,R9
191 2RS1-10-821J R chip resistor 1005, 820Ω±5% 1 R174
192 2RS1-10-513J R chip resistor 1005, 51K±5% 1 R270
193
5OC1-50R0-DSB32-2
509
SMD crystal oscillator
KDS, model DSB321SDN,
50.4MHz, 0.5ppm, -40
3.2*2.5*0.9mm
1 U1
194 1IS1-LT1901A-MCU
MCU + baseband
processing IC
LT1901A, for radio S566 1 IC19
195 2RS1-10-304J R chip resistor 1005, 300K±5% 1 R181
42
