Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
196 5XT1-MC146-32R76K E SMD ceramic resonator
32.768KHZ, MC-146, 12.5PF,
20PPM, lead free
1 X301
197 3FW1-0805L035 Fuse
0805L035 350mA, PTC,
Littlefuse
1 FB49
198
1ID1-TS3A24159DGS
R
Single-pole double-throw
analog electronic switch
TS3A24159DGSR, lead free 1 IC4
199 2RS1-10-4R7J R chip resistor 1005, 4.7Ω±5% 2 R14,R15
200 2RS1-10-472J R chip resistor 1005, 4.7K±5% 1 R19
201 1IS1-TDA2822 ER SMT IC TDA2822 1 U600
202 1IS1-LTJIAMI Encryption chip LTJIAMI, for radio DP585 1 IC18
203
1IM1-H8ACS0PG0AB
R-A
MCP
Hynix, H8ACS0PG0ABR IC,
1Gb (128Mb x8) NAND Flash +
512Mb (32Mb x16) mobile SDR
1 IC20
204 2RS1-10-202J R chip resistor 1005, 2K±5% 1 R225
205
5OT1-26R0-HHL-030
3
SMD temperature
compensated crystal
oscillator
26MHz±2ppm, -30 ℃~+85 ℃,
2.8V, 3.2*2.5
, Xiamen Yixin, lead
free
1 Y3
206
2CC1-10-X5R160-10
5K
Multi-layer chip capacitor
1005, 1uF±10%, 16V, X5R,
Murata
1 C170
207
2CC1-10-X7R250-22
3K
R multi-layer chip
capacitor
1005, 22nF±10%, 25V, X7R 2 C462,C465
208 2RS1-10-204J R chip resistor 1005, 200K±5% 3 C464,R253,R299
209 4PE1-16-F2
R SMD light emitting diode
1608, red light,
19-21SUR/S530-A2/TR8
1 D24
210 4PE1-16-F5
R SMD light emitting diode
1608, green light,
H19-213SYGC
1 D25
43
