Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
211 1DR1-ESD9B5 TVS diode
ESD9B5.0ST5G, 5V, SOD923,
lead free
7 D26,D27,D28,D32,D33,D34,D35
212 1IS1-ADS1015 A/D converter IC
ADS105IRUGT, 10-pin, QFN
encapsulation, Texas
Instruments, lead free
1 IC2
213 1IS1-DAC104S085
D/A converter chip (for
radio DP585)
DAC104S085, VSSOP
encapsulation
1 IC9
214 1DR1-TPD4S012DRY TVS diode
TPD4S012DRY, 4-CHANNEL
ESD SOLUTION FOR
USB-HS/USB OTG/USB CH
1 IC21
215
1ID1-MXD2020ML
SMD universal logic IC
MXD2020ML, LCC-8, lead free
1
IC22
216
1IM1-AT24C512C
SMD memory
AT24C512C, ATMEL, lead free
1
IC23
217 3CF1-BL112-20RL
R SMD FPC/FPC
connector
Spacing 0.5mm, 20-pin,
horizontal type
1 J2
218 3CF1-BL112-30RU SMD FFC/FPC connector
Spacing 0.5mm, 30-pin,
horizontal type
1 J3
219 3ST1-SKRTLBE010 R SMD tact switch
SKRTLBE010, 4.5*3.55*3.3mm
(ALPS)
1 S1
220 7MDC-4207-01A-W
VCO shield cover (for
radio DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, square, 31.05*13.3*3,
Chuanghong brand, lead free
1 P1
221 7MDC-4207-02A-W
GPS shield cover (for
DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, heteromorphic,
33*13.05*3, Chuanghong brand
,
lead free
1 P2
222 7MDC-4207-03A-W
Automatic power control
(APC) shield cover
Copper-Nickel-Zinc alloy, 0.2
mm thick, square,
1 P3
44
