Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
Position
(for DP586) 21.3*11.45*2.2, Chuanghong
brand, lead free
223 7MDC-4207-04A-W
Power shield cover (for
radio DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, square, 16.2*15.1*2.3,
Chuanghong brand, lead free
2 P4,P5
224 7MDC-4207-05A-W
Amplifier shield cover (for
radio DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, square, 16.3*10.95*2,
Chuanghong brand, lead free
1 P6
225 7MDC-4207-06A-W
Baseband shield cover
(for radio DP586)
Copper-Nickel-Zinc alloy, 0.2
mm thick, heteromorphic,
44*19.97*2.3, Chuanghong
brand, lead free
1 P7
226 6PM7-4295-HMB Main board DP585-01
DP585_MAIN, 1.2mm thick,
FR-4, 106X46mm, 6-layer, lead
free
1
227
3SE3-ED08C03O-FE
18C9
Encoder switch
ED08C03O-FE18C9.0-A16-100
2, Changtaier brand, axial
diameter 4.75mm, M6 thread
1 S2
228
3SE3-ED08E42S-FE1
5C7
Power encoder switch
ED08E42S-FE15C7.0-A16-1020
, with location column, axial
diameter 4.75mm, axial length
15mm, Changtaier brand
1 S3
229 6BLS-MS621FE Button cell
MS621FE (Manganese and
Silicon), Lithium, 3V, 5.5mA,
chargeable, lead free
1 BT2
45

Kirisun DP580 Specifications

General

Brand	Kirisun
Model	DP580
Category	Two-Way Radio
Language	English
