DP580 Service Manual
8 7MHR-4072-06A-W0 O-shaped ring
Silicon rubber, outer diameter 4 mm, wire diameter 1.0 mm,
Xincheng brand, lead free
2
9 7MHR-7042-06B-W0 R heat-conducting silicon pad
Silicon rubber, black, 3*6*9mm, softer than Level-A one, lead free,
1
10 7MHL-4207-01B-W Aluminum housing for radio DP586
ADC12, surface grinding, sand blasting, paint spraying, Zhaoda
brand, lead free
1
SMA-J, install using flange, 7200 times of use
Antenna connector nut for radio TP660
Brass, black nickel plated
13
7SMF-020040M-SZY
B-N
R M2*4 cross recessed mushroom-head
machine screw
558/PT4200/PT558S/5200/PT
Hardened iron, Φ2mm*4mm, nickel plated, metric coarse thread,
nylok
13
14
7SMF-020037M-SZC
T-N
M2.0*3.7 cross recessed countersunk-head
machine screw
P570/DP570/PT3500S/GD-9/GD-9V
Hardened iron 1018, Φ2.0mm*3.7mm, nickel plated 2
15
7SMS-025075M-SZY
B-N1
M2.5*7.5 torx round-head machine screw Stainless steel, Guangfenglong brand, lead free 2
16 7MHC-4072-01A-W STP knob nut
Brass, inner diameter 6mm, outer diameter 9mm, 2.4mm thick,
2
Stainless steel, T=0.3, original color, Junyu brand, lead free
18 6PD7-4207-HPB PTT board for radio DP586
DP586_PTT_1600707, thickness 0.8MM, FR-4, 52*10mm, 2-layer,
lead free
1
19 7MHS-4207-03A-W PTT metal dome array for radio DP586 SUS301, Φ5mm, four-point metal dome, Lixinghui brand 1
20
B-Z
M2.5*8 cross round-and-mushroom headed
machine screw
Stainless steel, Φ2.5mm*8mm, black zinc plated, Guangfenglong
brand, lead free
2
21 7MBM-S4207-A Conductive foam of speaker for radio DP586 With dual-sided conductive adhesive, 12*7*2.2mm, Xinlongda brand 1
22 4SS7-4005-016-100F Speaker (P8D)
ND040GM15610, 16Ω, 1W, Φ40*H5.0, Fushengda brand, with small
PCB spring connector, lead free
1
