Kirisun DP580 Service Manual

DP580 Service Manual
SN
Part NO.
Part Name
Specification
QTY
23
7GCB-445285-W0A
Speaker dust screen
Nylon net, 44.5*28.5mm, 0.1mm thick, Xinlongda brand, lead free
1
24
7MBP-4230-01B-W0
Front housing
PC1414, black, etched, screen print, mending etching, Santai brand
1
25
7MBP-4230-02A-W8
Front shell cover
PC1414, black, etched, Santai brand, lead free
1
26
7MHR-4207-05A-WC
Light pipe for radio DP586
Silicon rubber, hardness 60±5°, transparent, Xindahui brand
1
27
7MHR-4207-04A-W3
Alarm key for radio DP586
Silicon rubber, pantone 172C, hardness 60±5°, Xindahui brand
1
28 7MHR-4207-03A-W0 Silicon PTT key for radio DP586 Silicon rubber, black, hardness 60±5°, Xindahui brand, lead free 1
29 7MHP-4207-04A-W0 PTT cover for radio DP586 (cover die 1) PC1414, black, etched, Santai brand, lead free 1
30 7MHP-4207-05A-W0
Side key cap (up) for radio DP586 (cover die
1)
PC1414, black, etched, Santai brand, lead free 1
31 7MHP-4207-06A-W0
Side key cap (down) for radio DP586 (cover
die 1)
PC1414, black, etched, Santai brand, lead free 1
32 7MHP-4207-01A-W0 Plastic PTT key for radio DP586
PC1414, co-molding dual-color, pantone 172c+, black, etched,
Santai brand, lead free
1
33 7MHJ-4207-02B-W
Dual-sided adhesive tape for earphone
FPCB (for radio DP586)
3M9448, square, 20.3*7.8mm, lead free, Xinlongda 1
34 7MHF-4207-01C-W
Cover sticker of earphone FPCB (for radio
DP586)
PC, T=0.2mm, single-sided adhesive, with locating angle C, lead
free, Xinlongda brand
1
35
7MHR-1727-09A-W3
R 558 hand microphone case
Silicon rubber, hardness 40°, orange, no surface treatment
1
36 7GCB-070045005-J
Microphone cloth (for radios DP770 and
PT567)
White waterproof sound-transmitting membrane, with plastic mesh,
7*4.5*0.1mm, single-side adhesive
1
37 6PF7-4207-HK1D
Dual-sided earphone FPCB (for radio
DP586)
DP586_Earphone_170612, 48.6*25.2*0.2mm, 2-layer, lead free,
2-layer, lead free
1
38
2CC1-16-C0G500-47
1J
R multi-layer chip capacitor 1608, 470P±5%, 50V, C0G 1
39 4SM7-6027-A40B
R earphone for handheld radios (558S,
7200, 558, S785)
Φ6.0mm, 2.7mm high, -40dB±2dB, omni-directional, 2.2KΩ,
2V(B6027AP402-65)
1
40
7MHP-1010-15A-W
R PVC pad for microphone
Transparent PVC, 0.5mm thick, 3208
1
41 7MJP-4038-01E-W0 KBJ-17 belt clip
ABS, black, thickened and enhanced, meshed, coarse textured,
Mingli brand, lead free
1
83

Kirisun DP580 Specifications

General

Brand	Kirisun
Model	DP580
Category	Two-Way Radio
Language	English
