Kirisun DP990 Service Manual

DP990/DP995service manual
17
13
7MHP-4182-01A-L6
Side key, black and orange
1
14
147K01000067
Top housing, black, no screen print, etched
1
15
4SM7-4002-A44
Waterproof microphone (with case) (new waterproof
sound-transmitting membrane
1
16
157F15000085
Sponge for display screen, black
1
17
157F15000060
Foam for FPC stiffener, black, adhesive, 6.0*4.0*1.0
1
18
4SS7-4072-016-015C
Waterproof speaker, IP68, Φ40, H=5±0.3mm, 16Ω, 1.5W
1
19
7MHC-4182-02A-W
Speaker holder, 0.7mm thick, stainless steel, natural color
1
20
147K04000020
Master waterproof ring, silica rubber, orange, high elasticity
1
21
121M01000027
LCD module, 1.77''
1
22
147K02000092
LCD support, stainless steel, original color, 0.4mm thick
1
23
6SS2-4127-HFB
62DI000132
Panel PCBA suite (with BT), panel, PCBA, without BT
1
24
6SS1-4127-HK1A
Main FPC nesting
1
25
157F15000086
Sponge mat, black
3
26
7SMF-020040M-SZYB-N
Cross recessed mushroom-head machine screw, nickel plated, metric
coarse thread, Φ2mm*4mm
1
27
3SE3-RE08110NX-V0
Stepless channel encoder, IP68
1
28
3SE3-RE08110NX-V02B
Stepless channel encoder, IP68
1
29
2RW3-RP08110SNJX-V2B
Potentiometer switch, IP68
1
30
7MJS-4142-02A-W0
F9 PTT key spindle, stainless steel, original color, SUS304
1
31
7PLP-4182-01A-W0
Sticker for TF card holder, PVC
1
32
7MHR-4182-05D-W0
Waterproof silicon rubber cover for TF card (wire drawing), stainless
steel and silicon rubber, orange
1
33
6SS1-4127-HK2B
Past Mask nesting for encryption board
1
34
7SMF-014030M-SZCT-N
Cross recessed countersunk-head machine screw, low-carbon steel,
nickel plated
1
35
7MHR-4072-06A-W0
O-shaped ring, silicon rubber, outer diameter 4 mm, wire diameter 1.0
mm
6.5
36
147K03000008
Aluminum housing, original color, ground, sand blast and
electroplanted surface
1
37
7SMS-025075M-SZYB-N1
Torx round-head machine screw, stainless steel, M2.5*7.5
4
38
157F15000083
Waterproof breathable membrane, White, φ7.1*φ5.3*0.3mm, IP68
1
39
7SMS-025270M-SZYB-N1
Torx round-head machine screw, nickel plated
2
40
6SS3-BJ4188-A
KBJ-19 belt clip, black
1
41
7SMF-025080M-SZYB-Z
Cross round-and-mushroom headed machine screw, black zinc plated,
Φ2.5mm*8mm
2
42
7MBP-4072-04A-W0
Top housing, black, etched
1
43
7MHR-4182-03A-W0
Heat-conducting silicon-rubber pad, black, 30*8*0.5mm
1
44
7MHR-4182-01A-W0
Discharge waterproof pad, hardness 30°, silicon rubber, orange
PT172C
1
