Kirisun DP990 Service Manual

DP990/DP995service manual
18
45
4MV3-KFF081522
DC vibration motor
1
46
7MHR-4072-09A-W0
Motor case, silicon rubber, yellow
1
47
7MHS-4072-02A-W
STP press plate of motor, stainless steel, original color
1
48
62DI000215
Mainboard DP990-02, 400~470 MHz, GPS/BDS, Man down, 4W,
hardware V2.0
1
62DI000194
Mainboard DP990-01, self-locking, crystal compatible, overdischarge
protection
62DI000219
Mainboard DP990, 400~480 MHz, GPS/BDS, Man down, 4W,
hardware V1.0
49
7MHP-4072-03A-W0
Pad for coding/volume knob, PET, 23*9.5*0.4mm
1
50
7MHR-4072-04A-W0
Top waterproof pad, silicone rubber/stainless steel,black
1
51
7MHS-4072-01A-W
STP press plate of alarm key, stainless steel, original color
1
52
8ATX-4187B-FPC-BT
FPC BT antenna, 0.2mm thick,30mm coaxial cable,IPEX connector
1
53
7MHP-4072-04A-W0
PVC pad, transparent, Φ5.0mm*2.0mm*0.3mm
1
54
7GCM-020015010
Sponge mat, EVA, black, adhesive, 1.0mm thick
2
55
7MBP-4072-05B-W0
Auxiliary cover board (reinforced rib), PC+silicon rubber, black,
etched
1
56
7MHS-4072-01A-W0
Screw for auxiliary, stainless steel, black, black zinc plated
1
57
7MHF-4072-01A-W
Cover for auxiliary PCB, black, screen print, transparent, one-side
adhesive
1
58
6SS1-4072-HL1A
Auxiliary board SMD nesting
1
59
7MHJ-4072-01A-W
Dual-side waterproof adhesive for auxiliary PCB
1
60
6SS1-4188-HLA
SMD auxiliary FPC board
1
61
157F15000043
EVA R rubber pad, black, adhesive, 10.0*9.0*2.0mm
1
62
7MHB-4334-01A-W0
Conductive cloth for front shielding cover , 40.5*19.5*0.1mm
1
63
157F15000069
Highland barley paper, 24*8*0.2mm, 0.2mm thick, single-side
adhesive
1
64
7MHC-4072-01A-W
Knob nut, brass,inner diameter 6 mm, outer diameter 9 mm, 2.4mm
thick
2
65
7MBR-4182-01A-WC
Light pipe, silicon rubber, transparent
1
66
7MHS-4072-08A-W
Knob circlip, stainless steel, T=0.3, original color
2
67
147K01000052
Volume knob, black, etched, white oil brushed
1
68
147K01000051
Coding knob, black, etched, white oil brushed
1
69
7MHR-4182-01A-W3
Alarm key, silicon rubber, PT 172C
1
70
3CR7-S4182-A
RF coaxial connector, brass, 1/4-36, gold plated, lead free
1
71
7MHR-4182-04A-W0
Waterproof pad for antenna connector
1
72
7NRC-090115025-W1
Antenna connector nut
1
73
8ATX-151162-WD
Antenna, 151-162MHZ, with GPS/BD, 147mm long
1
8ATX010006
Antenna, GPS/BD, 400-480MHz, 99±2mm
8ATX-350400-WF
Antenna, 350-400MHZ, with GPS/BD, 120mm long
74
7MHJ-4182-04B-W
Dual-side waterproof adhesive for glass
1
75
7MBP-4182-06A-W0
Glass, PMMA/PC composite, T=1.5, transplant; screen print
1
