12
INSTALLATION
INSTALLATION
■
Inside/End Mount. Use your marks to position each bracket and mark each of the
screw holes.
➤
For 4” Fascia, the minimum mounting depth required and fully recessed depth is 4
1
⁄
8
”.
➤
For 3” Fascia, the minimum mounting depth required and fully recessed depth is 3
1
⁄
8
”.
■
Drill the screw holes using a
1
⁄
8
” drill bit.
■
Attach the installation brackets using the screws provided.
➤
End Mount Shims (Optional). To ensure light gap is even on both sides, you may need to shim the bracket. Do not tighten
the screws fully. Orient the shim as shown. Slide the in between the bracket and window casement. Tighten the screws fully.
WARNING: Product is heavy. Mount into wood/metal studs or into concrete with concrete anchors. Drywall anchors are
not recommended.
Proceed to “STEP 3: Install the Shade” on page 18.
Shim
(Optional)
