Kirsch Roller & Screen Shade - Dual Roller Shades - Outside Mount

14
INSTALLATION
INSTALLATION
Dual Roller Shades - Outside Mount
The installation brackets are always mounted so that the inner surfaces face each other. The brackets must be mounted so the
shade is level wheninstalled.
■
Center the ordered width measurement over the window at the desired height and mark its location.
■
Remove the adhesive backing on the wire retainer and place it to the upper back corner of the motor-side bracket.
■
Place the outside edge of the idle-side bracket on the previously made mark and mark each of the screwholes.
➤
A minimum 5
1
⁄ 2 ” flat vertical surface is required to mount the brackets.
➤
The top of the installation brackets should be at the desired height. The brackets should be level andaligned.
Use this measurement
to mark the location
for the motor-side
bracket.
Previously
Made Mark
Outside Mount – Left Side
Wire
Retainer
