KitchenAid KDTM405PPS - Product and Cabinet Opening Dimensions

11
PRODUCT AND CABINET OPENING DIMENSIONS:
.
B
A
C
D
E
23
7
/8"
(60.4 cm)
30"
(76.2 cm)
30"
(76.2 cm)
24½"
(62.6 cm)
3/4"
(1.9 cm)
3¾"
(9.7 cm)
20
13
/16"
(52.9 cm)
33
5
/8"
(85.4 cm)
minimum with
legs removed
3
1
/2" - 4
1
/2"
(8.4 cm - 10.6 cm)
A. Insulation may be compressed (not used on all models).
B. For panel-ready models, dishwasher depth is 24"
(61.0 cm), not including the 3/4" (1.9 cm) custom door
panel.
C. Door handles may protrude forward of the face of the
dishwasher, varies by model.
Check that all surfaces have no protrusions
that would prohibit dishwasher installation.
33
5
/8" minimum
(85.4 cm) minimum
21"
(53.4 cm)
3"
(7.6 cm)
4"
(10.2 cm)
24"
(62.0 cm)
2"
(5.1 cm)
6¼"
(15.9 cm)
NOTE: Shaded areas
of cabinet walls
show where utility
connections may be
installed.
D. Measured from the lowest point on the underside of
the countertop. May be reduced to 33
5
/8" minimum
(85.4 cm) minimum by removing the feet and perforated
area of insulation (blanket) on dishwasher.
E. Minimum, measured from narrowest point of opening.
