4-2
REMOVING THE COOKTOP
NOTE: The electronic control is part of the
cooktop and cannot be serviced separately.
1. Turn manual gas line shutoff valve to the
closed position.
2. Unplug cooktop or disconnect power.
3. Remove the burner grates from the cook-
top.
4. Pull the knobs off the gas valves.
5. Remove the burner caps and bezels from
the standard burner bases.
6. Remove the components from the Crown
burner.
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
7. Remove the three T-20 screws from the
crown burner base and the two screws
from each of the standard burner bases.
Gas Valve Knobs
Cap
Bezel
Standard Burner
Screws (2 each)
Crown Burner
Screws (3 )
Cap
Spreader
Spreader
Bezel
Burner Grates
To Next Page
