4-13
REMOVING THE POWER SUPPLY CORD
1. Unplug cooktop or disconnect power.
2. Remove the cooktop (see page 4-2 for the
procedure).
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
Power Supply Cord
3. Remove the screw from the power supply
cord ground wire.
4. Press the locking tab on the power supply
cord connector and disconnect it from the
main connector.
5. Remove the strain relief from the power
supply cord and pull the cord out of the
burner box mounting hole.
Power Supply Cord
Connector
Ground Wire Screw
Strain Relief
To Next Page
