Appliance operates correctly but one or more User Interface indicators do not operate
POTENTIAL CAUSES
ACTION
1.1.1
Check wiring between User Interface and UI connector on the igniter module
1.1.2
Checkthe User Interface connectors on the igniter module and User Interface are
correctly aligned and located in locking tabs.
1.1.3
Check that the pins on the Receptacles are not contaminated and mate
correctly. Excessive wear may deteriorate a positive connection.
1.2.1
Check the wiring to the P1 Connector on the igniter module,16Vac, N connections
1.2.2
Check 16Vac taps ( both ) on the Isolating transformer within the appliance is
functioning correctly as per transformer specification
1.2.3
Checkthat the P1 connector are correctly aligned and located in locking tabs of
the ignitermodule.
1.2.4
Check pins on P1 connector and Receptacles are not contaminated
and mate correctly. Excessive wear may deteriorate a positive connection.
Faulty IGNITER
module
1.3
Replacement module corrects the fault
Faulty User Interface
1.4
Replacement module corrects the fault
Problem with Power to
the igniter module
Bad connections
between igniter module
&User Interface
Turn on all the Cooktop Burners, either one at a time or all together. The associated User Interface lamp will illuminate. No
sparking is evident at the spark gaps of any Burners.
The associated click when sparking cannot be heard. Unignited gas
flows while the burner is on.
POTENTIAL CAUSES Action
2.1.2
Check Voltage between P1-3and P1-2 is V=16Vac
Voltage at the IGNITER Module
Power Terminals 120Vac,N
below 96Vac
2.2.1
Check transformer coil resistances
2.1. 3Check Voltage between P1-3and P1-2 is V=16Vac
2.1.1
Check connector at P1 and P2 are correctly aligned and located in locking tabs.
Faulty IGNITER module
2.3 Replace the igniter module if steps 2.1.3 -2.2.1 are good.
Verify replacement module corrects the fault
No Power to the IGNITER
Module Spark circuitry
To Next Page
