KITO CX005 User Manual

11
Specifications
Operating environmental conditions
Installation
Read the "Safety precautions : Mounting" on page 6 carefully before use and follow the instructions.
- The safety factor of the chain hoist is 4:1. The hoist may lift and hold a load more than the rated load. Check that the structure for mounting the
chain hoist has sufficient strength.
- Only allow trained or competent persons to install the chain hoist.
- Do not install the chain hoist within the moving range of other devices (equipment), such as a trolley.
- Before using the chain hoist with a trolley, read the Instruction Manual of the trolley carefully and install it by adjusting the rail width.
Install a stopper at both ends of the traversing rail for the trolley.
- If the adjustment of the bottom of the hand chain between 500 mm and 1000 mm from the ground is required, consult KITO.
Note: KITO TS trolley (Models TSP005) can be connected to this hoist. When using the CX003 by connecting to a
trolley, change the capacity on the trolley nameplate to 250kg, corresponding to CX003. For details, contact
KITO.
Do not use the chain hoist in the following environments:
- In an alkaline/acidic atmosphere
- In an organic solvent/explosive atmosphere
Incidentally, when you wish to use the chain hoist in environments other than the aforementioned normal use environments, such as one with a high
salt content, or in an environment where outdoor use in particular is extensive, it may be possible to use the chain hoist by carrying out maintenance
inspection frequently. In such cases, consult with KITO beforehand.
This device was tested according to the required static and dynamic load test provided on the European standard EN 13157.
*1: Average hand pull to lift the rated load.
*2: Length of the hand chain necessary to lift a load 1m.
Preoperational check
Read the "Safety precautions : Mounting" on page 6 and "Safety precautions : Maintenance" on page 9 carefully
before use and follow the instructions.
The user must carry out a daily inspection before operation.
Even if the chain hoist is permanently installed and used for the same purpose repeatedly, check all the works for the
day and check to ensure that it does not exceed the rated load on each occasion.
Operating temperature range -40°C to +60°C
Operating humidity range Use the hoist at under 100%RH. This product cannot be used in water.
Materials
Standard materials are used.
Special materials such as sparkless materials and asbestos are not used.
With regard to the environmental load substances, 6 substances defined in the
RoHS directives are not contained in this product.
Product
code
Rated load
(t)
Standard lift
(m)
Minimum
Headroom (mm)
Standard length of the hand
chain double fold (m)
Pull to lift Load
*1
(N) [kgf]
Hand chain length
for 1m lifting
*2
(m)
CX003 0.25 2.5 217 2 147[15] 33.8
CX005 0.5 2.5 260 2.5 187 [19] 42.8
Product
code
Load chain diameter x pitch
(mm)
Chain fall lines
Test Load
(t)
Weight for additional 1m
of lift (kg/m)
Mass
(kg)
CX003 3.2 x 9.0 1 0.313 0.4 2.4
CX005 4.3 x 12.0 1 0.625 0.9 4.5
