Item Method Discard limit or criteria Action
Body Visually check the Pawl Shaft. • Pawl shaft should be secured to Body. Replace the Body
Assembly.
Visually check and measure
the bearing hole of Frames
A and B for the Load Sheave
with a vernier caliper.
• Should be free of substantial deformations
or aws.
• The dimensional difference between "a" and
"b" should be 0.5mm or less.
Replace the Frame A or
B.
Visually check and measure
the bearing holes of Frame
B for the Gear with a vernier
caliper.
Should be free of signicant deformations or
aws.
• The dimensional difference between "a" and
"b" should be 0.5mm or less.
• Should be free of deformation of the Frame.
Replace the Frame B.
Visually check the
deformation and aw of the
Gear Case.
Should be free of signicant deformations,
aws or cracks.
Replace the Gear Case
Assembly.
Visually check and measure
the abrasion of holes of the
Gear Case for the Plain
Bearings with a vernier
caliper.
Should be free of signicant deformations or
aws.
• The dimensional difference between "a" and
"b" should be 0.5mm or less.
Replace the Gear Case
Assembly.
Visually check and measure
the deformation and abrasion
of the Top Pin with a vernier
caliper.
Signicantly deformed Top Pin has reached
the discard limit.
Replace the Top Pin.
a
b
Plain Bearing
A
a
b
a
b
Frame A
Frame B
b
a
Pawl Shaft
Rated load (t)
Dimension A (mm)
Standard Limit
0.25 8 7.6
0.5
10 9.6
