KITO CX005 User Manual

31
Range Category Check Item
Date of Check
Periodic
Inspection
Top/Bottom
Hook
Deformation of hole to combine the Top Yoke
Deformation of Bottom hook connection hole (for CX005 only)
Abrasion of the first link of Chain at the load end.
Braking
mechanism
Abrasion and flaw on the braking surface
Abrasion and crack on the Friction Plate
Abrasion of Bushing
Oil impregnation of Bushing
Abrasion of Ratchet Disc
Abrasion of Pawl
Deformation and abrasion of Pawl Spring
Corrosion (rust)
Abrasion of contact surface of Bushing of Friction Disc
Lifting
mechanism
Abrasion and flaw of Load Sheave
Abrasion and flaw of Load Gear and Gear #2
Deformation of Pinion
Abrasion and flaw of Hand Wheel
Deformation of Cam Guide
Torsion and deformation of Hand Chain
Abrasion and flaw on tooth of Pinion
Body
Deformation of hole for Top Pin
Deformation of holes on Frames A and B for bearing
Deformation and flaw of Gear Case
Abrasion of plain bearing of Gear Case
Deformation and abrasion of Top Pin
Others
Deformation of Chain Guide
Deformation, abrasion, and corrosion (rust) of End Pin
Test
No load test
Rated load test
Check mark example: ○＝ Good, △＝ To be replaced (adjusted) at next inspection, ＝ Defective. To be replaced (adjusted)
When any defect is observed during inspection,
stop using the Chain Hoist, indicate Failure/
Inspection underway and consult with the
competent person or KITO for repair.
Use of a faulty Chain Hoist may result in death or severe injury.
Mandatory
This Check Sheet is a standard sample based on
KITO frequent and periodic inspection. Customers
should decide upon their own format of the check
sheet according to the operation environment
and conditions of the customer, and perform the
inspection. Be sure to include all check items into
the check sheet.
NOTE
Inspected by
Inspector
Checked by
Competent person
