KITO EQ series User Manual

119
Appendix Frame and wheel, motor, gear
A
Frame and wheel, suspension shaft
In Diagram Part Number
Part Name
Quantity per unit
Part Code
Remark
MR2Q010IS
1 5201 Side plate G assembly 1 MR1DS5201
2 1231 Track wheel G assembly 2 M6SE010S1101
3 233 Ball bearing 2 J1GR020-06302
4 234 Snap ring 2 J1SR000-00042
5 235 Washer 2 T6GA010-9104 For track wheel G
6 236 Snap ring 2 J1SS000-00015 For track wheel G
7 1211 Side roller complete set 4 S.R SET 010
8 5202 Side plate S assembly 1 MR1DS5202
9 1232 Track wheel S assembly 2 M6SE010S1102
10 233 Ball bearing 2 J1GR020-06302
11 234 Snap ring 2 J1SR000-00042
12 2101 Suspension shaft complete set (150) 1 MR2DI2111 Beam width: 58-153mm
13 101 Suspension shaft (125) 1 M7SE010S9115
14 102 Thick spacer 5 T4GA010-9116
15 103 Bolt 1 T1GA010-9153
16 104 Slotted nut 1 J1NL002-10100
17 105 Split pin 1 J1PW01-025018
18 106 Shaft stopper 1 T6GA020-9156
19 107 Split pin 1 J1PW02-040020
21 109 Thin spacer
8
T6GA020-9117
125kg, 250kg, 490kg, 500kg
14 1t
22 110 Thick spacer L 2 MR1DS9110
23 113 Thin spacer L 13 MR2DI9113
12 1121 Suspension shaft complete set (300) 1 MR2DI1112 Beam width: 154-305mm
13 121 Suspension shaft (300) 1 M7SE010S9181
14 102 Thick spacer 9 T4GA010-9116
15 103 Bolt 1 T1GA010-9153
16 104 Slotted nut 1 J1NL002-10100
17 105 Split pin 1 J1PW01-025018
18 106 Shaft stopper 1 T6GA020-9156
19 107 Split pin 1 J1PW02-040020
20 108 Fixing spacer (300) 2 M7SE010S9182
21 109 Thin spacer
8
T6GA020-9117
125kg, 250kg, 490kg, 500kg
14 1t
22 110 Thick spacer L 2 MR1DS9110
23 113 Thin spacer L 2 MR2DI9113
Motor, gear
In Diagram Part Number
Part Name
Quantity per unit
Part Code
Remark
MR2Q010IS
1 247 Ball bearing 1 J1GR020-06002 For gear #3 on gear frame side
2 248 Gear frame packing 1 MR1DS9248
3 249 Set pin 2 MR1DS9249 For gear frame and frame G
4 250 Bolt 4 J1BA1-0802525
For gear frame. Integrated type with spring/flat waher is
available. (251 and 252 are not necessary.)
5 251 Spring lock washer 4 J1WS011-20080 For gear frame
6 252 Washer 4 J1WA011-00080 For gear frame
7 253 Ball bearing 1 J1GR060-06204 For gear frame on motor side
8 5261 Brake drum assembly 1 MR1DS5261
9 264 Brake spring 1 M3ES010-9304
10 265 Bumper 1 MR1DS9265
11 281 Guard 1 MR1DS9281
12 5291 Motor shaft with rotor 1 MR1DS5291
13 293 Oil seal 1 MR1DS9293
14 1301 Motor cover assembly 1 MR1DS1301
15 304 Socket bolt 4 J1BE1-0802222 For motor cover
16 5321 Motor frame with stator 1
MR2SJY10S5A2
400V
MR2SJC10S5A2
230V
17 324 Terminal cover 1 M6FE005S9206
18 325 Terminal cover packing 1 MR1DS9325
19 326 Coil cover 1 MR1DS9326
20 331 Machine screw with spring washer 4 J1AP2-5001010 For terminal cover
21 332 Machine screw with spring washer 2 J1AW2-4002020 For terminal plate
22 334 Machine screw with spring washer 1 J1AP2-4000808 For ground
23 851 Terminal 6P 1 M6FE005S9516
24 1241 Gear complete set 1 MR1DS1241
