54
■
Installing the Trolley Combined Model
■
Mounting the Hoist to the Travel Rail
Sling
3) Install the electric chain hoist combined with the trolley to the rail from its one end
2) Set the wheel at Frame G side of the
Trolley Frame on the running face of the
Travel Rail. Then push the Frame S into
the Frame G.
1) Assemble the Trolley temporarily using
the hole B of the Lifting Shaft and install
the electric chain hoist from the bottom
side of the Travel Rail.
●
When the gap between the rail end and the wall of the housing is scarce
3) Insert the Shaft Stopper Pin into the Hole
A of the Suspension Shaft. Then mount
a split pin securely.
• Securely support the electric chain hoist Mode EQ not to tilt.
Failure to comply with this instruction causes bodily injury or loss of property.
Mandatory
CAUTION
1) Make sure that the dimensions of the Trolley Frame satisfy the size of the rail to which
the trolley is installed.
2) Make sure that the rail is set to a level.
Hole B
Frame G
Frame S
Sling
Hole A
Lifting Shaft
1
InstallationInstalling the Trolley Combined Model
Assembling (continued)
Chapter 1 Handling the Product
To Next Page
