KITO EQ series User Manual

121
Appendix Connection box related
A
In Diagram Part Number
Part Name
Quantity per unit
Part Code
Remark
MR2Q010IS
1 1401 Connection box complete set 1
MR2IVD10R1A4 400V
MR2IVE10R1A4 230V
2 341 Holder A 1 ECP5924AA
3 342 Holder B 3 ECP5924AB
4 343 Packing 3 ECP5924AC
5 344 Holder nut 3 ECP5924AD
6 347 Cord cover 1 E6LE010S9630
7 348 Machine screw with spring washer 4 J1AP2-5000808 For Cord cover
8 349 Plate D 1 ECP5924AF
9 401 Connection box 1 MR1DS9401
10 411 Connection box cover 1 MR1DS9411
11 421 Connection box packing 1 MR1DS9421
12 422 Machine screw with spring washer 4 J1AP2-5001010 For Connection box cover
13 423 Spacer 4 M6SE010S9517
14 424 Machine screw with spring washer 4 J1AP2-8002020 For connecting Connection box and Frame
15 1445 Plate complete set 1
MR2IVD10R1A5 400V
MR2IVE10R1A5 230V
16 441 Plate 1 MR2DI9441
17 443 Plate B 1 MR2DI9443
18 451 Machine screw with spring washer 3 J1AP2-4000808 For grounding
19 452 Machine screw with spring washer 2 J1AW2-4000808 For Terminal 3P
20 467 Machine screw with spring washer 4 J1AP2-4000808 For Plate B
21 1571 Inverter assembly 1
INV602Y31 400V
INV604C31 230V
22 573 Braking resistor 1
INV904Y34 400V
INV904E34 230V
23 580 Machine screw with spring washer 2/4 J1AP2-4001010 For inverter, 2 pieces for 230V and 4 pieces for 400V
24 581 Machine screw with spring washer 2 J1AW2-4000808 For Braking resistor
25 716 HBB board 1 ECP91KB22
26 853 Terminal 3P 1 ECP1403AA
27 863 Inverter lead wire 1set MR2IVA10R9A5
28 454 Machine screw with spring washer 4 J1AP2-5001010 For Plate complete set
29 1751 Relay cable 4C assembly 1 MR2DS2760 For power supply
30 1570 Holder assembly 1 *
31 751 Relay cable 4C 1
Z2CU401-0000
32 341 Holder A 1 ECP5924AA
33 351 Cable packing 1 ECP6912AA
34 1761 Relay cable 5C assembly 1 MR2DI2766 For operation
35 1570 Holder assembly 1 *
36 341 Holder A 1 ECP5924AA
37 351 Cable packing 1 ECP6910AA
38 761 Relay cable 5C 1 Z2CA500-00000
39 818 Cord cover packing 2 M7SE010S9527
40 820 Machine screw with spring washer 4 J1AP2-5000808 For Plate D
41 701 Name plate B 1
EQ1BEE04I9A3 490kg
EQ1BUQ10I9A3 1t
42 702 Name plate D 1
EQ1BUQ01I9A6 125kg [Affixed on Name plate B (1t)]
EQ1BUQ03I9A6 250kg [Affixed on Name plate B (1t)]
EQ1BUQ05I9A6 500kg [Affixed on Name plate B (1t)]
43 834 Name plate SP 1 MR2IVD10R9B7
44 711 Warning seal E 1 ER2DPX10S9866 Electric shock
*
When ordering, let us know the product model, part number and part name.
