KITO EQ series User Manual

123
Appendix Push button and cable related
A
In Diagram Part Number
Part Name
Quantity per unit
Part Code
Remark
MR2Q010IS
1 1781 Push button cord 8C assembly 1 ZLDD01AW1000
2 341 Holder A 1 ECP5924AA
3 351 Cable packing 1 ECP6912AA
4 781 Push button cord 8C 1 Z3CA800-0000
5 783 Warning tag PB 1 SWD9013AB
6 784
Tag holder
1 E7SE003S9787
7 1801 5 push button switch assembly 1 SWJ2220AC
8 1481 Bar holder assembly 1 MR1DS1481
9 481 Bar holder 1 MR1DS9481
10 816 Cord chain stopper 1 E6LE010S9614
11 817 Machine screw with spring washer 2 J1AP2-6001212 For cord chain stopper
12 482 Socket bolt with spring washer 2 J1BG1-1002828 For bar holder
13 1771 Power supply cable 4C assembly 1 ZBZC12AJ1000
14 351 Cable packing 1 ECP6914AA
15 1724
Cable support 14 assembly
1
E4YS005-2822 230V, 400V class
Cable support 16 assembly M3ES010-1724 230/460V class
16 741 Name plate G 1 E6LE010S9806
17 771 Power supply cable 4C 1 Z2CU402-0000
18 1641 Cable hanger 14 assembly n E6AX003S1527
19 1491 Cable support bar complete set 1 MR1DS1491 For power supply cable
20 491 Cable support bar 1 MR1DS9491
21 492 Cable support arm 1 MR1DS9492
22 1493 Wire guide assembly 1 MR1DS1493
23 501 Support bar holder (plate) 1 MR1DS9501
24 505 Bolt 2 J1BA2-0803030 For support bar holder (plate)
25 506 Spring lock washer 2 J1WS012-20080 For support bar holder (plate)
26
511 Cable hanger pusher 1 MR1DS9511 For T-type hanger (Beam 75mm)
512 Cable hanger pusher 1 MR1DS9512 For T-type hanger (Beam 100-150mm)
27 516 Socket bolt 2 J1BG1-1002828 For cable hanger pusher
28 1791 Trolley cable 4C assembly 1 MR2DS1791
29 341 Holder A 2 ECP5924AA
30 342 Holder B 1 ECP5924AB
31 343 Packing 1 ECP5924AC
32 351 Cable packing 2 ECP6912AA
33 791 Trolley cable 4C 1 Z2CU401-0000
