KITO ER2 - Page 123

123
■
Single Speed Model
(500V Class Dual Speed
Model)
■
Dual Speed VFD Model (Body size B, C)
■
Dual Speed VFD Model (Body size D, E, F)
Inverter
Controller cover
Panel
Limit switch
Packing C
Braking resistor
Nameplate
Resistor cover
Interface board
Inverter
Controller cover
Braking resistor
Nameplate
Panel
Limit switch
Resistor cover
Interface board
Packing C
A
Product Structure and Names of Each Part
Controller cover
Panel
Limit switch
Packing C
