KITO ER2 - Product Specification and Operational Environment

16
Product Specification and Operational Environment
■
Standard Specification
Short time ratings : ER2 series(Capacity 100 %) : Single speed model — 60 min.
Dual speed VFD model (high speed/low speed) — 30/10 min.
: MR2 series(Capacity 100 %) : Single speed model — 30 min.
Dual speed VFD model (high speed/low speed) — 30/10 min.
Intermittent ratings : ER2 series(63 % of the capacity) : Single speed model — 60 % ED (at 360 rev/h)
Dual speed VFD model (high speed/low speed) — 40/20 % ED
(120/240 rev/h)
: MR2 series(63 % of the capacity) : Single speed model — 40 % ED (at 240 rev/h)
Dual speed VFD model (high speed/low speed) — 27/13 % ED
(78/162 rev/h)
Grade * 1 : ISO-M6, M5 or M4, FEM-3m, 2m or 1Am, ASME-H4
Protection : Hoist IP55, Push button IP65
Operation Push button switch operation / 3-Push Button Switch set for hoist only and Manual trolley type / 5- or
7-Push Button Switch set for motorized trolley combined model
Power supply method....Power supply through cabtyre cable
Color...............................KITO Yellow (Equivalent to Munsell 7.2YR6.5/14.5)
Noise level : ER2, single speed 75dB or less (A scale: measured at 1 m away from the Electric chain hoist)
: ER2, dual speed VFD model 80dB or less (A scale: measured at 1 m away from the Electric chain hoist)
: MR2 85dB or less (A scale: measured at 1 m away from the Electric chain hoist)
Braking capacity : 150% of the capacity or more
Other...............................Power Cable length 5 m/10 m (Standard)
NOTE
• Operate the electric chain hoist with the rated voltage.
• Do not use the electric chain hoist exceeding the short time ratings and the intermittent ratings.
The operational environment of the electric chain hoist and motorized trolley is as follows:
Chapter 1 Handling the Product
1
Product Specication and Operational Environment
Standard Specication
Product category
Motor Insulation
Class
Voltage range
Operating
Voltage
50Hz 60Hz
230V Class B
220V 220V
24V
(24V~26.4V)
230V 230V
400V Class F
380V 380V
400V 440V
415V —
500V Class B 500V 575V
230/460V Class B
208-230V
110V
(110V~121V)
415-460V
Capacity (kg or t)
Code GRADE Code GRADE
Single speed Dual speed ISO ASME FEM Dual speed ISO ASME FEM
125 ER2-001H ER2-001HD
M5 H4 2m
ER2-001IH
M6 H4 3m
250
ER2-003H ER2-003HD ER2-003IH
ER2-003S ER2-003SD ER2-003IS
500
ER2-005L ER2-005LD ER2-005IL
ER2-005S ER2-005SD ER2-005IS
1
ER2-010L ER2-010IL/LD
ER2-010S ER2-010IS/SD
1.5 ER2-015S ER2-015IS/SD
2
ER2-020L ER2-020IL/LD
M4 H4 1Am
ER2-020S ER2-020IS/SD
2.5 ER2-025S ER2-025IS/SD
2.8 ER2-028S ER2-028IS
3 ER2-030S ER2-030IS/SD
5 ER2-050S ER2-050IS/SD
* Grade
* For 125kg - 500kg dual speed VFD type equipped with friction clutch with mechanical brake, the grade is ISO M5
and FEM 2m.
