Kiturami TURBO CONDENSING - 13 - Burner Construction

OIL CONDENSING BOILER
INSTALLATION AND USER MANUAL
INSTALLATION & USER MANUAL www.krb.co.kr 12
2.2. Burner construction
Fig. 2.3 Exploded view of burner
1 Burner motor 8 Burner upper casing
2 Burner tube 9 Venturi pipe
3 Burner lower casing 10 Primary fan
4 Secondary fan 11 Flame detector
5 Oil nozzle 12 Fan casing
6
7
Nozzle adapter
Ignition rod
13 Air damper
