Kiturami TURBO CONDENSING - 13 - Specification for Combustion

OIL CONDENSING BOILER
INSTALLATION AND USER MANUAL
INSTALLATION & USER MANUAL www.krb.co.kr 47
Power Consumption W 104 104 104
Standby power W 5 5 5
Standby loss W 0.111 0.111 0.111
Range of temperature control
°C 45~85
Max Temperature range °C 85
Gas volume of the boiler ㎥ 0.00846 0.00846 0.00846
The required draught mbar
0.1 0.1 0.1
Gas side resistance and
combustion chamber pressure
for boilers operating with
positive pressure
mbar 0.2 0.2 0.2
Water resistance mbar
10K : 380 / 20K : 480
8.2. Combustion specifications
Item Unit
TURBO
CONDENSING-13
TURBO
CONDENSING-17
TURBO
CONDENSING-21
Thermal output
(condensing)
kW 13.6~16.6 17.8~21.7 21.9~26.8
Thermal output
(Normal)
kW 12.9~15.8 16.7~20.4 20.4~24.9
CO emission rating Class 1 1 1
NOx emission rating Class 1 1 1
Smoke level No. 0 0 0
Exhaust gas temperature
(Normal / Condensing)
°C 85/60 90/65 95 / 70
Exit flue gas mass flow kg/s 0.0069 0.0093 0.0117
