3.5. Flue installation
3.5.1. General method for flue installation
Fig. 3.4. Flue installation method
A Min. 15 cm from the ceiling a Boiler flue tube (supplied)
B Min. 40 cm from the wall b Incombustible material
C Min. 40 cm from the wall c Flue tube finish material (supplied)
Fig. 3.5. Correct installation of the flue tune
Do not install the exhaust end of flue inside the wall.
The flue tube must be protruded into outdoor sufficiently for smooth exhaustion.
