OIL CONDENSING BOILER
INSTALLATION AND USER MANUAL
INSTALLATION & USER MANUAL www.krb.co.kr
13
2.3. Other components
Fig. 2.4. Flue set components
Fig. 2.5. Accessories
1 Flue adapter 7 Power cord 13 Oil hose bushing
2 Extending tube 500 mm 8 Condensate drain hose 14 User's Manual
3 Exhaust flue 9 Cleaning brush 15 Room temperature controller
4 Extending tube 300 mm 10 Condensate hose clip 16 Flue tube band
5 Elbow 11 Oil hose
6 Finish material 12 Oil filter
