KLS Martin marLED E15 - Tracking Arm Circuit Diagrams; Circuit Diagram Circuit Diagram for for 3-Pole Tracking Arm 3-Pole Tracking Arm with Backlite with Backlite Option Option



Service ManualService Manual
Operating Lights marLEDOperating Lights marLED
®®
E9 / E9i / E15E9 / E9i / E15
V V 1.0 1.0 1515
4.34.3 Tracking Arm Circuit DiagramsTracking Arm Circuit Diagrams
4.3.14.3.1 Circuit Diagram for 3-Pole Tracking Arm with backLite OptionCircuit Diagram for 3-Pole Tracking Arm with backLite Option
A
A Tracking Tracking arm arm B B Spring Spring armarm
1 1 Plug Plug for for connection connection to to ceiling ceiling tube tube 4 4 Socket, Socket, tracking tracking arm arm sideside
2 2 Slip Slip ring ring 5 5 Socket, Socket, light light head head sideside
3 Plug3 Plug
6 6 backLite backLite connection connection optionoption
When using a combination of lights, please note the different color marks on the connectors.When using a combination of lights, please note the different color marks on the connectors.
Tracking arm 1:Tracking arm 1:

red red Tracking Tracking arm arm 3:3:

blueblue
Tracking arm 2:Tracking arm 2:

yellow yellow Tracking Tracking arm arm 4:4:

greengreen
NOTICENOTICE
