KLS Martin marLED E15 - Opening Casing and Replacing Control Electronics



Service ManualService Manual
Operating Lights marLEDOperating Lights marLED
®®
E9 / E9i / E15E9 / E9i / E15
V V 1.0 1.0 3939
6.66.6 Opening the casingOpening the casing
Danger of electrocution!Danger of electrocution!
The lamp is operated at 100–240 VAC!The lamp is operated at 100–240 VAC!
For all work on the lamp, turn off the customer-side power supply and secure it againstFor all work on the lamp, turn off the customer-side power supply and secure it against
reactivation.reactivation.
Risk of property damage due to falling Risk of property damage due to falling parts!parts!
The lamp must not be opened as long as it is fixed to the suspension system! The lamp mustThe lamp must not be opened as long as it is fixed to the suspension system! The lamp must
be taken down first (see installation manual marLED marLux, chapter 9 “Lamp Installation /be taken down first (see installation manual marLED marLux, chapter 9 “Lamp Installation /
TFT Suspensions”).TFT Suspensions”).
••
 Remove all three Light Engines (see sectionRemove all three Light Engines (see section
Kapitel 6.5 “”, page 37).Kapitel 6.5 “”, page 37).
The lamp body screws (1) are now accessible.The lamp body screws (1) are now accessible.
••
 Unscrew lamp body screws (1).Unscrew lamp body screws (1).
WARNINGWARNING
NOTICENOTICE
