42
14” CRUMBLER
FINISHING TOOL OPTIONS:
20” CRUMBLER
Finishing Tools on the 6700 Series Rip Strip are optional ac-
cording to the customer’s preference. Above are the different
combinations of finishing tools that KMC offers as standard
options. Your preferred finishing tools should come pre-assembled on the 6700 Series Rip Strip
machine. Refer to the “Layouts for Standard Tillage Set-up” in this section to verify placement of
your particular finishing tool option. All the finishing tool options should be mounted behind the rip
strip tillage tools and centered behind each ripper shank. If there should be a need to reposition any of
the finishing tools, loosen the appropriate hardware and relocate, making sure to fully support the item
being moved, if completely taken off the rear toolbar. Once all items have been repositioned and
secured, re-tighten all loosened hardware. (Refer to the “Bolt Torque Chart” at the first of this
section for proper assembly torque). Note: Finishing tools should center behind the ripper shanks.
16” TIRE ROLLER
20” TIRE ROLLER
TANDEM 20” CRUMBLER
TANDEM 20” CRUMBLER
& 20” TIRE ROLLER
