30
Dual Tillage w/14”Crumbler
(67-DC-SC)
Dual Tillage w/16”Tire Roller
(67-DC-SR)
NOTE:
THE TILLAGE COULTERS ARE STAGGERED BACK
IN THE MIDDLES WHERE THE GAUGE WHEELS
ARE POSITIONED.
6 1/4 6 1/4
8 5/16
6 1/4
6 1/4
9 1/8
NOTE:
THE TILLAGE COULTERS ARE STAGGERED BACK
IN THE MIDDLES WHERE THE GAUGE WHEELS
ARE POSITIONED.
Quad Tillage w/20”Crumbler
(67-QC-LC)
6 1/4
6 1/4
1010
11 1/4
NOTE:
THE TILLAGE COULTERS ARE STAGGERED BACK
IN THE MIDDLES WHERE THE GAUGE WHEELS
ARE POSITIONED.
Quad Tillage w/20”Tire Roller
(67-QC-LR)
6 1/4 6 1/4
10 10
11 1/4
NOTE:
THE TILLAGE COULTERS ARE STAGGERED BACK
IN THE MIDDLES WHERE THE GAUGE WHEELS
ARE POSITIONED.
** All Tillage Set-ups to be centered behind ripper shanks.
LAYOUTS FOR STANDARD TILLAGE SET-UP:
