Kodak CR 7400 User Manual

6H4130 – September 2007 17
Section 4: KODAK CR 7400 System Setup
During all phases of Kodak CR 7400 system setup, the unit must be turned on and the USB cable connected between
the unit and the computer.
Initial setup
[1] Click on the Kodak Dental Software icon on the computer desktop.
[2] Select a patient and click “imaging” to access the imaging window.
[3] Click the CR icon.
The user interface screen appears:
User interface screen
To start scanning, choose and set your preferences as follows:
[4] Click the Info/Setup button.
[5] Select Technician Settings. The login screen appears:
[6] Enter the password “1331” in the password field, and click Login.
Info/setup
button
